The main entrance and reception to the office accommodation lies on the north face of the building. Bar and restaurant space is provided at ground and first floor levels on the south-facing elevation, with large terraced areas fronting the landscaped piazza, big screen and waterfront.

The main features are:

  • Double height glazed facade
  • Two glazed revolving doors with a disabled access pass door
  • Double height foyer
  • Striking white Corian reception desk with black glass frontage
  • Integral seating area
  • Feature lighting

Building Fabric
Highly efficient curtain walling system with diamond shaped unitised cladding panels.

External Lighting
An external lighting scheme, comprising both accent and active lighting, washes the external elevations in light and accentuates the building within the site wide lighting scheme.

5 no. 17-person passenger lifts
1 no. 2000kg goods lift serving all floors.

Secure Access Control System CCTV system
Managing access and egress to the building coupled with a CCTV system controlled from main reception.

Building Management System (BMS)
Controlling all building services, designed to allow a Cat B enhancement of the controls to enable sub-division.

Ladies, Gents and Disabled WC and & shower facilities to each floor.

Fully accessible metal plank with recessed lighting and ventilation grilles, designed on a 1500mm x 1500mm module.
Floor to ceiling height – 2.8m (top of raised floor to underside of suspended ceiling).

All lighting is compliant with the CIBSE code for interior lighting and complies with Part L2 of the building regulations. The lighting design provides average illumination levels of 400 lux across the office areas.

Fully skimmed, dry lined and decorated throughout.

Full access raised floors with a floor zone of 150mm.


Comfort Cooling / Heating
4 pipe fan coil units providing heating and cooling.
Return air to the fan coil units is via dedicated return air grilles in the ceiling.

The services infrastructure serving the building comprises: electrical, telecoms, gas, water, tri-gen heating and sprinklers.

Design Occupancy

  • Heating / cooling services: 1:8 m2
  • Lifts (diversified): 1:10m2
  • Fire Escape: 1:6m2
  • WC provision: 1:14m2
  • With future proofing provision up to: 1:8m2

The accommodation benefits from access to the MediaCityUK private HV network which has a current supply provision of 32MVA. Downstream, LV supply solutions are available to meet bespoke requirements.

The premises are connected to site wide fibre infrastructure. Technology packages can be tailored to meet occupier requirements.
